Air Locker For Toyota Landcruiser ARB RD90

[PROVIDES 100% TRACTION]

• Vastly improved traction means less reliance on momentum, reducing the likelihood of vehicle damage.

[COMFORT AND SAFETY]

• Easy, convenient operation without leaving the comfort and safety of the driver's seat.
• Ultra-durable and powerful; only the highest quality materials are used in construction.
• Patented gear technology and 2-piece design ensure optimal locking strength.
• Forged gears provide superior strength and durability.
• Incredibly simple yet effective, the design employs minimal moving parts for maximum reliability.

[EFFECTIVE DESIGN]

• Thoroughly tested and proven.
• Most sold as kits with differential, activation switch, solenoid valve, airline, and bulkhead fittings.
• Front and rear Air Lockers available for most makes and models
• For 4WD and 2WD applications.
• Easy maintenance; no special additives required
  They are also offered in ARB Traction Packs include two Air Lockers, a compressor, and accessories for tire inflation.

ABOUT THIS PRODUCT

ARB Air Locking Differentials For Competition/Off-Road/Rock Climbing.
Installation of the ARB RD90 air locker should be performed by a qualified differential technician. However, no special tools or skills are required apart from those necessary for fitting a standard differential. When installed with an ARB air compressor (high output or mini), the locker system is supplied as a complete kit that contains all of the parts necessary for proper installation, including industrial-grade control switches, air lines and fittings. ARB offers two compressor models suitable for Air Locker operation (high output air compressor or mini air compressor). A dedicated air activation system is available which is highly durable and compact. Alternatively, a larger compressor can be specified, which is also perfect for inflating tires, air mattresses and a host of other applications where compressed air is required.

SPECIFICATIONS

• Dimensions (L x W x H): ‎10.63 x 10.63 x 11.02 inches.
• Ring Gear OD 191mm [7.5”].
• Axle Spline 27 tooth, Ø28.0mm [1.10”].
• Ratio Supported All.
• Ring Gear ID 118.0mm [4.65”].
• Ring Gear Bolts 10 bolts on Ø140mm [5.51”].
• Ring Gear Torque 96Nm [71 ft-lb].
• Backlash 0.13-0.18mm [0.005-0.007”].
• Bearing Cap Torque 85Nm [63 ft-lb].
• Does Not Affect Road Drivability/Driveline Wear.
• Reduces likelihood of vehicle damage/environmental impact.
• Easy/convenient operation.
• Allows concentration on terrain.
• Ultra durable and extremely strong.
• Incredibly simple yet effective design.
• Employs minimal moving parts ensuring maximum reliability.
