OME 2.5 inch Tacoma 16-21 Lift Kit (Heavy Load) Old Man Emu Suspension OMETAC-3GEN-2.5HVY Fits 3rd Gen Toyota Tacoma

IN STOCK & READY TO SHIP! All products (excluding Out of Stock tagged) are ready to ship the same or the next day.

Features

• Enhanced Ride Quality and Control On & Off-Road.
• Increased load carrying capacity by 200 lbs Front and 800 lbs Rear.
• Increased Ride Height & Ground Clearance by 2.5 Inches.
• Can Accommodate Larger Tires (see details below for more info).
• Includes a 3-Year / 37,200 miles Manufacturer Warranty.
• Fits Toyota Tacoma Models 2016-2021 (3rd Gen).

Set Includes (In the Box)

Note:  Some products on the main image are optional.

CONSIDER ↴

Upper control arms

ENHANCE OVERALL PERFORMANCE

When an Independent Front Suspension (IFS) vehicle is fitted with a suspension lift, the caster and camber can be pushed outside the factory specifications. IFS vehicles generally have a few degrees of adjustment in their camber and caster from the factory. Adding Old Man Emu upper control arms brings the alignment cams back into an acceptable range for both caster and camber.

The OME Upper Control Arm will provide an increase between +2.5 and +3.5 degrees of caster and up to 1.5 degrees of negative camber increase (figures based on an approximate 50mm or 2in the lift)

Click here to learn more about UCA

Top hat kit

PROTECT YOUR STRUTS WITH OME TOP HAT KIT

Old Man Emu engineers have developed a complete replacement Top Hat solution that incorporates all required components to replace the original Strut Top hat fully. This includes a new bearing plate, high Duro rubber isolator, rubber bushes, washers, crush tube (if applicable), and mounting nuts.

All components are to the original equipment specifications and are a straightforward bolt-in solution.

Click here to learn more

Details

- Easy bolt-on installation.
- Est. Install Time: 2-4hrs.
- This lift kit fits: Toyota Tacoma 3rd Generation (2016, 2017, 2018, 2019, 2020 & 2021).
- Recommended Tire Size: 265-75R16 (31.65”), 285-75R16 (32.83”), 265-70R17 (31.65”), 275-70R17 (31.65”).
- Recommended Wheel Backspacing: Factory.
- Does NOT fit models equipped with X-REAS system.
- Does not fit Pro series models.
- SKU: OMETAC-3GEN-2.5HVY

THE OME DIFFERENCE

This Kit was specifically designed for your car by Australias best engineers. So it is not just a compilation of parts to increase the vehicle’s ride height. It is a tuned, matched, and integrated suspension system that results in optimum levels of comfort (ON and OFF Road), load-carrying capability, and control characteristics.

The rear set of nitrogen-charged N3 shocks offer an incredible balance of on and off-road ride quality. With a 100% bolt-on installation process, this Kit is easy to install in a home garage with standard tools.

Ome takes integrations to the next level with its selection of bushings, U-bolts, center bolts, spring liners, trim packers, and suspension fitting kits. Old Man Emu employs a team of full-time ride control engineers who carry out exhaustive testing and development on each component.

During development, each new suspension system is tested not only for functional performance but also to ensure compatibility with modern vehicle safety features such as electronic stability control, an area in which ARB has invested heavily.

Take your ride to the next level with OME!
