ARB Differential Breather Kit 170112

[HIGH CAPACITY]

• The axle breather manifold is machined from billet aluminium and anodized, making it lightweight and resistant to the elements.
• The manifold has 4 axle breather ports allowing for between 1 and 4 breather lines to be connected. It is very compact allowing it to be installed in virtually any location.
• The kit comes with self tapping screws, but the manifold mounting holes are large enough to allow mounting using an M6 (1/4"") bolt or stud, which is the common size in most vehicle engine bays.
• The air filter is the ARB compressor air filter, which is a splash resistant air filter with a washable high flow sintered bronze filter cartridge.
• 8mm Polyethylene tubing is flexible, oil resistant, water resistant and heat resistant.

ABOUT THIS PRODUCT

The axle breather manifold is machined from billet aluminium and anodized, making it lightweight and resistant to the elements.The manifold has 4 axle breather ports allowing for between 1 and 4 breather lines to be connected. It is very compact allowing it to be installed in virtually any location.
The kit comes with self tapping screws, but the manifold mounting holes are large enough to allow mounting using an M6 (1/4 inch) bolt or stud, which is the common size in most vehicle engine bays.The air filter is the ARB compressor air filter, which is a splash resistant air filter with a washable high flow sintered bronze filter cartridge.
8mm Polyethylene tubing is flexible, oil resistant, water resistant and heat resistant.
8mm tubing has been selected over the standard 6mm tubing to improve the air flow and reduced the chance of oil blockages in long breather lines.
The 8mm push-in fittings make the installation simple and fast.

KIT INCLUDES THE FOLLOWING ITEMS

• 4 x 1/8""BSP ports for connecting up to 4 breather lines.
• 1 x 1/4"" NPT ports for the air filter.
• 4 x 8mm-1/8""BSP push-in fittings.
• 3 x 1/8""BSP plugs for plugging unused ports.
• 8m x 8mm polyethylene tubing.
• 2 x self-tapping screws.
• 25 x cable ties.

SPECIFICATIONS

• Dimensions (L x W x H): ‎10.63 x 10.24 x 5.51 inches.
• Weight ‎15.9 ounces.
